Ubiquiti NanoStation Loco M2

The Ubiquiti NanoStation Loco M2 is a compact and cost-effective wireless CPE (Customer Premises Equipment) designed for point-to-point (PtP) and point-to-multipoint (PtMP) applications. It's ideal for bridging networks over short distances or extending Wi-Fi coverage outdoors in challenging environments.

Key Features:

Compact Design: Small form factor for discreet installation, suitable for both indoor and outdoor deployments.
Powerful Performance: Operates on the 2.4 GHz frequency band with up to 150 Mbps real outdoor throughput.
Integrated Antenna: Built-in 8 dBi dual-polarity antenna for optimal performance and long-range connectivity.
Versatile Mounting Options: Includes a pole-mount kit for easy installation on poles or walls, allowing for flexible deployment.
AirOS Software: Intuitive and powerful AirOS software for configuration and management, providing advanced features and monitoring capabilities.
Weatherproof Design: Designed to withstand outdoor conditions with robust weatherproof housing, ensuring durability and reliability in harsh environments.
Passive PoE: Supports passive PoE (Power over Ethernet), allowing for single-cable installation and flexibility in deployment.

Applications:

The Ubiquiti NanoStation Loco M2 is suitable for:

Wireless Bridging: Establishing wireless links between buildings or remote locations where running cables is impractical.
Outdoor Wi-Fi Coverage: Extending Wi-Fi coverage to outdoor areas such as parks, campuses, and industrial sites.
Surveillance and Security: Providing connectivity for IP cameras and security systems in remote locations.
Public Wi-Fi: Creating public Wi-Fi hotspots for outdoor venues, events, and temporary setups.

Specifications:

Frequency: 2.4 GHz
Throughput: Up to 150 Mbps
Antenna Gain: 8 dBi
Ethernet Ports: 1 x 10/100 Mbps
Power Supply: 24V Passive PoE (included)
Mounting: Pole-mount kit included
Dimensions: 163 x 31 x 80 mm (6.42 x 1.22 x 3.15")
Weight: 180 g (6.35 oz)
Weatherproof Rating: IPX5

Package Contents:

Ubiquiti NanoStation Loco M2
Pole-Mount Kit
24V Passive PoE Adapter
Power Cord
Quick Start Guide

The Ubiquiti NanoStation Loco M2 offers a reliable and cost-effective solution for extending Wi-Fi coverage and establishing wireless links in outdoor and challenging environments, with robust performance and easy deployment.
